Product Details:
Payment & Shipping Terms:
|
| Material: | Resin,pigment | Color: | Customized Color |
|---|---|---|---|
| Curing: | 180-200℃，10-15minutes | Type: | Thermosetting Powder Coating |
| Coverage: | 7-12 M | Thickness: | 70-90um |
| High Light: | automotive powder coating,powder coating rust resistance |
||
FUNCTIONAL TYPES
Product Advantage
Independent products and color matching R&D Center
Better resins from DSM, higher resin content to ensure superior quality and higher rate of coating ratio
Better pigments to ensure better covering stronger anti ultraviolet and weather ability,
Service Advantage
Quality control inspection and establishment
Painting quality analysis
Production line review
Technology/Chemicals product analysis
Product Detail
| Test Item | Test Method | Test Result |
| Film Thickness | ISO2360 | 60-80um |
| Pencil Hardness | ASTMD 3363 | HB-H |
| Bending | ISO1519 | ≤10mm |
| Grid Test 1mm | ISO2409 | 0 Class |
| Impulse Test | ASTMD2794 | Pass |
| Cupping Test | ISO1520 | ≥8mm |
| Heat Resistance 1000 hours | ISO6270-1 | Popping<1mm |
| Salt Spray 1000 hours | ISO9227 | Corrosion Spreading<1mm |
Instruction
| Application Voltage | 60-90 KV |
| Gun to Component Distance | 15-30CM |
| Curing Temperature | 180-200℃,10 min-15 min |
Storage stability
| ♦ Store in ventilated, dry, clean room, temperature < 25℃ | ♦ Relative humidity 50-65% |
| ♦ Away from direct sunlight, fire, heat | ♦ For best performance, use within 6 months |
Product Description
We produced metall effect powder coating with bonding technical.Metallic flakes are sent through a process where friction and blending fuse the metallic to the powder particles, creating a bond.Benefits are improved application, broader range of appearances, and in some cases, can be reclaimed successfully.
Product Application
| ♦ Electrical Household Appliances | ♦ Aerospace Area |
| ♦ Automotive Electronics | ♦ Fitness Equipment |
| ♦ Track Traffic | ♦ Medical Devices |
| ♦ Petroleum Pipes, Valve | ♦ Tools & Hardware |
| ♦ LED Lights, Outdoor Lamps | ♦ Radiator & Heat Sink |
| ♦ Glass Decoration | ♦ External Facilities |
Company Exhibition
Partner
Authorized supplier for Nuclear Power Research and Desigh Institute of CNNC,which is central enterprises.
Authorized supplier for the world top 500 enterprises: , Carrefour, Hitachi etc.
Authorized supplier for famous domestic enterprises: Changhong, TCL, Wecome, Xiaomi etc.
F&Q
1. Are you a factory or trading company?
We are a factory located in Chengdu with many years manufacturing experience. You are most welcome to visit us at a convenient time.
2. Is Powder Coating safe for consumers such as children?
Yes. Powder Coating is used on children’s toys and furniture sold. It has the distinction of being one of the most environmentally and consumer friendly products on the market today.
3. What color are available to me?
We usually carry a very large range of colors. Has access to over 300 paint color and texture. Feel to call us and ask if we stock your required color. If not we can customize.
4. Are all the colors the same price?
NO. Some colors are more expensive due to their availability. Ingredients, such as texture powders, candies, metallic, glow in dark powders.
5. Where can I find pricing information?
Our pricing structure is dependant on volume, technology and color choice. Please contact us for specific product pricing.
6. Need more info?
We would love to help you with your Powder Coating questions and of course we look for ward to doing business with you. Let us know how we can help you.
