Indoor Powder Coating Customized Colors Epoxy Polyester

Brand Name:	Hsinda
Model Number:	ral k7
MOQ:	300kg
Price:	2.5USD/KG
Packaging Details:	Inner packing :polyethylene bag; Outer packing :paper carton
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

Chengdu

Certification:

ISO9001; SGS; ROHS

Main Raw Material:

Epoxy, Polyester ,epoxy Polyester Etc

State:

Powder State

Gloss:

High Gloos

Main Type:

Epoxy ,polyester ,epoxy Polyester Powder Coating

Raw Materials Brand:

DSM Resin , Dupont Etc

Curing:

180℃,10 Min-15 Min

Particle Size:

Average 30-42μm

Surface:

Smooth

Supply Ability:

50000TONS/YEAR

Product Description

Indoor Powder Coating Customized Colors Epoxy Polyester

Product Description

We offer a wide range of powder coating applications: medical devices, automotive, architectural, agriculture and furniture.With over 2000 colors in our powder database and a dedicated team of color experts, it’s no surprise. We can't put everything online, so contact us for sample chips, colors cards or more! Our shades include standard color ranges such as RALs, Federal Standards, ANSI and more, as well as elegant blacks and whites, inviting browns, greys, silvers and bronzes, eye popping neons, warm earthy tones, soft pastels, candy colors and striking translucents.

Epoxy polyester powder coating physical properties :

Appearance: regular, porosity

Specific gravity: 1.1 ~ 1.8 (owing to the different types and different colors)

The level of liquidity: 18 ~ 35 mm

Particle size distribution: 100% less than 125 microns with more than 85% between 60 ~ 90 microns

Curing conditions :Standard 180 ℃ temperature (workpiece) 15 minutes

Low temperature type 160 ℃ temperature (workpiece) 15 minutes

We offer a vast array of experience and information at your disposal. Explore our excellent technical tools, ideal for addressing a problem or for training purposes, including webinars available for viewing at your convenience, instructional videos, technical guides, and an ebook designed to navigate you through frequent challenges. Our guides have been written by our technical staff who have many years experience in all aspects of choosing powders, and solving technical problems.

Product overview

Type	Epoxy Powder Coating; Polyester Powder Coating; Epoxy-Polyester Powder Coating
Color	Ral&Pantone color
Surface Finish	Superior gloss and color retention
Particle Size	Average 32-42μm
Specific Gravity	1.2-1.7g per cubic meter
Coverage	8-10 square meters per Kg at 30-90 μm film thickness
Film thickness	Not less than 100μm

Instruction

Application Voltage	60-90 KV
Gun to Component Distance	15-30CM
Curing Temperature	180-200℃,10 min-15 min

Storage stability

Store in ventilated, dry, clean room, temperature < 25℃	Relative humidity 50-65%
Away from direct sunlight, fire, heat	For best performance, use within 6 months

Product process

Trade items of Products

Trade terms	FOB, CIF,CRF,CNF
Payment terms	T/T, L/C , West Union ,Moneygram , Paypal etc
Payment condition	30% deposit in advance,70% balance before shipment
Delivery time	3-7 days after deposit
Shipping	By sea, by air and by express delivery
	Sample Powder will be delivery by courier ,like DHL,UPS,FEDEX etc. 5-8 DAYS to arrival
	Official Order Powder will be ship by SEA .15-30 DAYS to arrival

Quality control:

Test Item	Test Method	Test Result
Film Thickness	ISO2360	60-80um
Pencil Hardness	ASTMD 3363	HB-H
Bending	ISO1519	≤10mm
Grid Test 1mm	ISO2409	0 Class
Impulse Test	ASTMD2794	Pass
Cupping Test	ISO1520	≥8mm
Heat Resistance 1000 hours	ISO6270-1	Popping<1mm
Shigh gloss mirror chrome sliver spray paint powder coating Spray 1000 hours	ISO9227	Corrosion Spreading<1mm
