| Brand Name: | hsinda |
| Model Number: | esu |
| MOQ: | 300kg |
| Price: | 5.5-12USD/KG |
| Payment Terms: | D/A, L/C, D/P, T/T, Western Union, MoneyGram，PayPal |
| Supply Ability: | 50000TONS/YEAR |
1. high voltage electrostatic spraying
2. Spraying voltage: 50-90 kV;
3. Air pressure for spraying: 0.1-0.2 Mpa
4. Distance between the gun and workpiece: 200-300 mm
5. Curing condition: 190℃-200℃/15-20 minutes or customized according to customers’ requirements.
Applications of Product
| ♦ Electrical Household Appliances | ♦ Aerospace Area |
| ♦ Automotive Electronics | ♦ Fitness Equipment |
| ♦ Track Traffic | ♦ Medical Devices |
| ♦ Petroleum Pipes, Valve | ♦ Tools & Hardware |
| ♦ LED Lights, Outdoor Lamps | ♦ Radiator & Heat Sink |
| ♦ Glass Decoration | ♦ External Facilities |
Powder coating is a combination of pigment and resin that is ground into a powder form and is sprayed on an item to be coated. The powder is charged with high voltage which is then attracted to the electrically grounded item to be coated. The item is heated in a curing oven until the powder flows into a liquid form. After curing for a specific amount of time, the part is removed to cool, leaving a high quality, durable finish.
Product detail
| Epoxy powder coating | Epoxy polyester powder coating | Polyester TGIC Powder Coating Polyester TGICfree Powder coating |
| Excellent anti-corrosion | Good chemical resistance | Excellent UV resistance |
| Excellent chemical resistance | Good mechanical performance | Excellent flexibility |
| High mechanical performance | Excellent flexibility | Excellent overbake stability |
| Recommended for interior | Recommended for interior | Recommended for exterior |
| Test Item | Test Method | Test Result |
| Film Thickness | ISO2360 | 60-80um |
| Pencil Hardness | ASTMD 3363 | HB-H |
| Bending | ISO1519 | ≤10mm |
| Grid Test 1mm | ISO2409 | 0 Class |
| Impulse Test | ASTMD2794 | Pass |
| Cupping Test | ISO1520 | ≥8mm |
| Heat Resistance 1000 hours | ISO6270-1 | Popping<1mm |
| Salt Spray 1000 hours | ISO9227 | Corrosion Spreading<1mm |
①We use the better resin
•Much higher first pass rate
•Better hardness
•Better abrasion resistance,flexibility
•Better chemical resistance
②We use better pigment
•Better hiding
•More mileage
•Stronger UV Stability and weatherability
•Lower necessary film thickness
③We use a higher resin content
•More excellent quality
•Higher first pass transfer efficiency
④We offer a higher stability between batches
•Higher First pass Rate on the line
•Much higher satisfaction
•Less customer claims
|
|
