| Brand Name: | Hsinda |
| Model Number: | ral/pantone color |
| MOQ: | 300kg |
| Price: | Negotiable |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000TONS/YEAR |
Antibacterial Wrinkle Finish Powder Coat High Strength Super Weather Resistance
Hsinda artistic texture series powder coating,including elephant texture, hammer texture, sand texture, crocodile texture, point texture, leather texture and orange texture and wrinkle texture powder coating and so on. it can provide epoxy,polyester,hybrid, pure polyester and other series, suitable for a variety of complex artistic texture powder coating indoor and outdoor, it is colorful or simple, and can cover the substrate defects, In the case of painting equipment and process stability , the texture of uniform and stable shape, decorative good, beautiful lines, good consistency.
Artistic texture series powder coating are based on:
1. Resin
2. Curing agent
3. Additives
4. pigments
Characteristic
1. Semi gloss effect
2. Matte effect
Appearance:
Artistic texture
Application:
Widely used in metal and decorative objects
Spraying technology:
1. Corona electrostatic spraying
2. Static fiction spraying
| Colour | wrinkle texture powder coating | Exp. Date | 10 month | ||
| Condition | 200℃,10minutes | Testing object | 0.5mm steel plate | ||
| No. | Items | Standards | Properties | Results | |
| 1 | Appearance | Visual | Loose | Loose,There is no cluster | |
| 2 | screenings | samples | 160 mesh sieve residue free | 160 mesh sieve residue free | |
| 3 | Film appearance | visual inspection | Clear texture | Clear texture | |
| 4 | Film thickness | GB/T 4957 | 70-90 | 70-90 | |
| 5 | Gloss(60°) | GB/T 9754 | / | 98 | |
| 6 | Adhesion | GB/T 9286-1998 | 0 | 0 | |
| 7 | Pencil hardness | GB/T 6739 | H-2H | 2H | |
| 8 | Impact resistance | GB/T 1732 | front back impact 50kg/cm | Pass,no crack | |
| 9 | Bend test | GB/T 6742 | ∮≤2mm | ∮≤1mm | |
| 10 | Colour difference | GB/T 9761-1988 | △E≤1 | △E≤1 | |
|
|
| Brand Name: | Hsinda |
| Model Number: | ral/pantone color |
| MOQ: | 300kg |
| Price: | Negotiable |
| Packaging Details: | Inner packing :thick plastic bag; Outer packing :export cardboard carton; Carton Size: 39*26*37cm ;Weight:20Kg/carton Gross Weight:21Kg/carton |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Antibacterial Wrinkle Finish Powder Coat High Strength Super Weather Resistance
Hsinda artistic texture series powder coating,including elephant texture, hammer texture, sand texture, crocodile texture, point texture, leather texture and orange texture and wrinkle texture powder coating and so on. it can provide epoxy,polyester,hybrid, pure polyester and other series, suitable for a variety of complex artistic texture powder coating indoor and outdoor, it is colorful or simple, and can cover the substrate defects, In the case of painting equipment and process stability , the texture of uniform and stable shape, decorative good, beautiful lines, good consistency.
Artistic texture series powder coating are based on:
1. Resin
2. Curing agent
3. Additives
4. pigments
Characteristic
1. Semi gloss effect
2. Matte effect
Appearance:
Artistic texture
Application:
Widely used in metal and decorative objects
Spraying technology:
1. Corona electrostatic spraying
2. Static fiction spraying
| Colour | wrinkle texture powder coating | Exp. Date | 10 month | ||
| Condition | 200℃,10minutes | Testing object | 0.5mm steel plate | ||
| No. | Items | Standards | Properties | Results | |
| 1 | Appearance | Visual | Loose | Loose,There is no cluster | |
| 2 | screenings | samples | 160 mesh sieve residue free | 160 mesh sieve residue free | |
| 3 | Film appearance | visual inspection | Clear texture | Clear texture | |
| 4 | Film thickness | GB/T 4957 | 70-90 | 70-90 | |
| 5 | Gloss(60°) | GB/T 9754 | / | 98 | |
| 6 | Adhesion | GB/T 9286-1998 | 0 | 0 | |
| 7 | Pencil hardness | GB/T 6739 | H-2H | 2H | |
| 8 | Impact resistance | GB/T 1732 | front back impact 50kg/cm | Pass,no crack | |
| 9 | Bend test | GB/T 6742 | ∮≤2mm | ∮≤1mm | |
| 10 | Colour difference | GB/T 9761-1988 | △E≤1 | △E≤1 | |
