Thermoset Powder Coating
>
Superior Gloss Thermoset Powder Coating , Oil Resistance Hybrid Powder Coating

Superior Gloss Thermoset Powder Coating , Oil Resistance Hybrid Powder Coating

Brand Name: Hsinda
Model Number: ral/pantone color
MOQ: 300kg
Price: Negotiable
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000TONS/YEAR
Detail Information
Place of Origin:
Chengdu
Certification:
ISO9001; SGS; ROHS
Main Raw Material:
Epoxy Polyester Etc
Application Method:
Spray
State:
Powder Coating
Gloss:
High Gloos/semi Gloss/matt/texture/candy
Main Type:
Epoxy ,polyester ,epoxy Polyester Powder Coating
Curing:
180-200℃,10 Min-15 Min
Particle Size:
Average 30-42μm
Texture:
Hybrid Epoxy Polyester
Supply Ability:
50000TONS/YEAR
High Light:

custom powder coating

,

heat proof powder coating

Product Description

Superior Gloss Thermoset Powder Coating , Oil Resistance Hybrid Powder Coating


Product Description


Main feature

A wide range of finishes and colours including metallic, glossy, rough and textured.

· Corrosion resistance.

· Powder coating can be applied to most metal components including steel, Zinc, brass and aluminium.

· The durable finish provides a surface finish which is less prone to chipping, marking and scratching.

· Powder coating can be applied to components used internally and externally.







170matt powder coating



Film Propert
Testing items Standards Methods Test index
Iimpact strength ISO 6272 GB1732-1993 40cm
Bending resistance ISO 1519 GB/T6742-1986 3mm
Adhesion ISO 2409 GB/T9286-1998 Grade 0
Cupping test ISO 1520 GB/T9753-1988 5mm
Pencil hardness ASTM D3363 GB/T6739-1996 H-2H
Salt spray test ISO 7253 GB/T1771-1991 More than500 hours
H&humidity test ISO 6270 GB/T17740-1979 More than1000 hours
Weatherability ASTM G151 GB/T1865-1997 240(QUV B313)




2. Other product

.jpg

  • Our Powder finishes are available in a vast range of colors and finishes.
  • Including metallic effect,chrome effect,wood grain,Candy Color Powder ,MDF powder
  • and other special effect,making them ideal for indoor decoration of steel furniture,
  • and outdoor metal products such as agricultural machinery, auto parts

3. product detail

Type

Epoxy Powder Coating; Polyester Powder Coating;

Epoxy-Polyester Powder Coating

Color Ral&Pantone color
Surface Finish Superior gloss and color retention
Particle Size Average 32-42μm
Specific Gravity 1.2-1.7g per cubic meter
Coverage 8-10 square meters per Kg at 30-90 μm film thickness
Film thickness Not less than 100μm

4. Instruction

Application Voltage 60-90 KV
Gun to Component Distance 15-30CM
Curing Temperature 180-200℃,10 min-15 min

5. Storage stability

Store in ventilated, dry, clean room, temperature < 25 Relative humidity 50-65%
Away from direct sunlight, fire, heat For best performance, use within 6 months



      Powder coatings are based on Resin,Pigments,Curing Agents,Additives.

  • Resin(including Epoxy, polyester, hybrid)giving the basic performance to the coating.
  • Pigments, Providing the colour and effects, such as metallic or hammer.
  • Curing Agents, reacts with the resin to form a continuous protective film.
  • Additives, can be used to promote variations in the performance or surface effects.
Packaging & Shipping



2.Trade items of Products

Trade terms FOB, CIF,CRF,CNF
Payment terms T/T, L/C , West Union ,Moneygram , Paypal etc
Payment condition 30% deposit in advance,70% balance before shipment
Delivery time 3-7 days after deposit
Shipping By sea, by air and by express delivery
Sample Powder will be delivery by courier ,like DHL,UPS,FEDEX etc. 5-8 DAYS to arrival
Official Order Powder will be ship by SEA .15-30 DAYS to arrival
. Product test

.jpg



1.Why choose us
